Product Details:
Payment & Shipping Terms:
|
| Name: | Freight Elevator | Load: | 3000~5000kg |
|---|---|---|---|
| Speed: | 0.25~0.5m/s | Control: | VVVF Elevator Control System |
| Flooring: | PVC | Application: | Cargo Lift |
| Drive Type: | AC | Material: | Stainless Steel |
| Model: | Freight Elevator | Type: | Freight Elevator |
| Highlight: | 5000kg Building Car Freight Elevator,Warehouse Cargo Lift 0.25m/s,Stainless Steel Freight Elevator |
||
Goods Elevator Building Car Elevator Freight Elevator Cargo Lift Warehouse
| Capacity(KG) | Speed(m/s) | Car Size (WxDxH)mm | Door Opening(WxD)mm | Shaft Size(WxD) | OH(mm) | Pit Depth(mm) |
| 3000 | 0.25/0.5 | 2700x5800 | 2400x2200 | 4100x6160 | 4800 | 1600 |
| 5000 | 0.25/0.5 | 3500x7200 | 2600x2200 | 4750x7560 | 4800 | 1600 |
Standard Functions
| 1 | Automatic stop | 16 | Anti-mischief function |
| 2 | Self-diagnostic of call button embedding | 17 | Auto-running of full-load |
| 3 | Car ventilation, light shut off automatically | 18 | Press hall button for re-opening |
| 4 | Repeat open/close door | 19 | Door load sensor |
| 5 | infrared Light curtain protection | 20 | Arrival tip |
| 6 | Fire running function | 21 | Self-diagnostic of elevator fault |
| 7 | Automatic lock/unlock the door | 22 | Current floor automatic opening of call |
| 8 | Terminal landing speed-adjustment by enforcement | 23 | Terminal landing prevention of offside |
| 9 | With/without driver operate | 24 | Overhaul running operation |
| 10 | Drivers choose orientation function | 25 | Auto- stop and rescue fault |
| 11 | Overload voice-light alarm and protection functions | 26 | The protection of high speeding |
| 12 | The preventation of no-stopping for enforce | 27 | Self-save information data of hoist way |
| 13 | The record of current floor calls | 28 | Automatic function of directional and changing direction |
| 14 | Internal auto-response and deceleration | 29 | Power-fail data protection |
| 15 | Running signal fault protection | 30 | Five-party interphone |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
Contact Person: Mr. Wei CHEN
Tel: +86-13661864321
